Mini Scissor by HYNEE
Product Overview
- The Mini Scissor by HYNEE is a versatile and efficient lifting platform suitable for indoor and outdoor use.
- It has a maximum working height ranging from 8m to 9.5m, with a loading capacity of up to 160kg.
- The product features an extension platform, chain self-leveling system, non-marking tires, swing out cover, oil collection box, and indoor/outdoor mode switch.
Product Features
- The extension platform with heavy-duty slide rails improves loading capacity and stability.
- The chain self-leveling system ensures equal tension on both chains for safety.
- The non-marking tires are lightweight, wear-resistant, and corrosion-resistant for a long lifespan.
- A swing-out cover provides easy access to inspect and maintain parts inside.
- The indoor/outdoor mode switch allows for versatile usage in different environments.
Product Value
- The Mini Scissor by HYNEE offers high-quality performance and durability for various lifting tasks.
- It provides a safe and efficient solution for working at height both indoors and outdoors.
- The product's advanced features enhance productivity and user convenience.
Product Advantages
- Efficient and reliable lifting platform with a maximum working height of up to 9.5m.
- Sturdy construction and innovative design ensure stability and safety during operation.
- Features such as the chain self-leveling system and extension platform enhance functionality and ease of use.
Application Scenarios
- The Mini Scissor by HYNEE is ideal for use in warehouses, factories, construction sites, maintenance tasks, and other industrial applications.
- It is suitable for tasks that require working at height in both indoor and outdoor environments.
- The versatile design and advanced features make it a valuable asset for various industries and businesses.
Hyneelift AMWP7.5-1100 self-propelled one person lifts are compact, low-weight machines that increase productivity on the job thanks to their ability to fit through doorways and in most passenger elevators. Driveable single person lift can be driven through doorways with operator on board. A zero inside turning radius and full elevation drive feature also contribute to these models’ increased productivity.
| Model | MVL9.5S |
| Max. Working Height | 9.50m |
| Max. Platform Height | 7.50m |
| Loading Capacity | 125kg |
| Occupants | 1 |
| Overall Length | 1.40m |
| Overall Width | 0.76m |
| Overall Height | 1.99m |
| Platform Dimension | 0.66m×0.67m |
| Wheel Base | 1.14m |
| Turning Radius | 0 |
| Travel Speed(Stowed) | 4km/h |
| Travel Speed(Raised) | 1.1km/h |
| Up/Down Speed | 53/45sec |
| Gradeability | 25% |
| Drive Tyres | Φ305×100mm |
| Drive Motors | 2×24VDC/0.5kW |
| Lifting Motor | 24VDC/1.3kW |
| Battery | 2×12V/100Ah |
| Charger | 24V/15A |
| Weight | 1190kg |
